ESP32-C3-MINI-1-N4 BLE/WiFi Module

With a very low form factor and smaller in size, ESP32-C3-MINI-1 is a great choice to be used in the IoT applications where space is a concern. This ESP32 module has smaller formfactor than the standard ESP32-WROOM-32D ot ESP32-WROOM-32E. It also supports excellent Wi-Fi and Bluetooth LE cores inside the module. This ESP32-C3-MINI-1-N4 comes with a 4MB Ram. It is and excellent microcontroller unit that can also be used for smart homes, industrial automation, health care, consumer electronics applications.

ESP32-C3-MINI-1 -N4 has an On-board PCB antenna that supports a 2.41-2.48 GHz of operations.

Feature of ESP32-C3-MINI-1-N4 –

1. Supports 20 MHz, 40 MHz bandwidth in 2.4 GHz
   band.
2. Built around ESP32C3 series of SoCs, RISCV single core microprocessor.
3. 4 MB flash in chip package available.
4. 15 GPIOs
5. PIO, SPI, UART, I2C, I2S, remote control
   peripheral, LED PWM controller, general DMA controller, USB Serial /JTAG controller, temperature sensor, SAR ADC, general-purpose timers, watchdog timers are available.

6. 40 MHz crystal oscillator.
7. Operating voltage/Power supply: 3.0 ~ 3.6 V.
8. WiFi Multimedia
9. 4MB Flash
10. 8 KB SRAM in RTC

Components Information of ESP32-C3-MINI-1 –

Manufacturer Part Number – ESP32-C3-MINI-1-N4.

Manufacturer Name – Espressif Systems.

Package – SMD.

Tips from Expert for advance users of ESP32-C3-MINI-1 –

1. Carefully Select strapping pins
2. Make sure to provide pull-up or pull-down properly

Pinouts of the ESP32-C3-MINI-1-N4

Package Information

1. 1x ESP32-C3-MINI-1 Module
